GTT 135
Send EnquiryGTT 135 is the second-generation model of the Dynamiq range of fast family cruisers of 41 meters.
The GTT 135 is the second-generation model in the Dynamiq range of fast family cruisers that was introduced with 39m Jetsetter in 2017. Built on an efficient and comfortable, round-bilge platform, the all-alumninium yacht can reach a top speed of 21 knots with a transatlantic range of 3,000nm at 12 knots. The new GTT 135 is half a meter wider and more than a meter longer than the previous model, but has retained a shallow draft of just 1.7m (just over 5.5 feet), which is ideal for the cruising the Caribbean, Mediterranean or Asian islands ...With the largest sundeck in her class, exceptional ceiling heights and five voluminous cabin, along with engineering and hydrodynamic design by leading Dutch naval architects, the new GTT 135 is the perfect realization of superyacht quality and comfort in a relatively compact package
Specification
-
- Hull type
- Round-bilge, fast displacement
- Length overall
- 41 meters / 135’
- Beam overall
- 8.2 meters / 26’11”
- Draft
- 1.8 m / 5'9’’
- Gross tonnage
- 299 GT
- Material
- Aluminium, 5083
- Main engines
- 2x MAN V12-1650, 1,213 kW
- Generators
- 2x 70 kW, Kohler
- Stabilisers
- Electrically driven, zero-speed function
-
- Max speed
- 21 knots
- Cruising speed (85% rpm)
- 19 knots
- Range
- 3,000 nm @ 12 knots
- Fuel
- 29,600 l / 7,820 US gallons
- Fresh water
- 9,500 l / 2,245 US gallons
Noise levels At anchor Cruising speed Main salon 40 dB(A) 59 dB(A) Owner suite 38 dB(A) 58 dB(A) VIP cabins 38 dB(A) 48 dB(A) Wheelhouse 38 dB(A) 50 dB(A) -
- Guests
- 10 (+1) in 5 cabins
- Crew
- 6 in 3 cabins
- Tender
- 5,4 m / 17’5”
- Classification
- RINA commercial, REG compliant
- Notations
- RINA Comfort Class, RINA Green Star
- Flag
- Cayman islands / Malta
- Exterior Design
- Dobroserdov Design
- Interior Design
- Giuseppina Arena / Dynamiq
- Build time
- 20 months
